Carbon Steel 45 Degree Elbow
What is 45 Degree Pipe Elbow Fittings?
A carbon steel 45 degree pipe elbow is a butt weld fitting manufactured from carbon steel that changes the direction of a pipe system by 45 degrees.
Compared with a 90° elbow:
Lower flow disturbance
Lower pressure drop
Smoother directional transition
Better for high-flow pipelines
Typical applications:
Oil pipelines
Gas transmission systems
Refinery piping
Steam lines
Water pipelines
Fire protection systems
Choose Carbon Steel 45 Degree Elbow when:
Fluid is non-corrosive
Cost control is important
Pipeline is protected by coating
Application is oil, gas, steam, water
|
Size: |
Seamless elbow:1/2"~24" DN15~DN600,Welded Elbow: 4"~78" DN150~DN1900 |
|
Type |
Pipe fitting |
|
Radius: |
L/R Elbow( 90deg & 45deg & 180deg.),S/R Elbow (90deg & 180deg.) |
|
Material |
Carbon steel |
|
standards |
ANSI,DIN,JIS,ASME and UNI etc |
|
Wall Thickness: |
sch10, sch20, sch30, std, sch40, sch60, xs, sch80, sch100, |
|
Manufacturing standard: |
ANSI, JIS, DIN, EN, API 5L, etc. |
|
Bending Angle: |
Degree 15, 30, 45, 60, 90, 135, 180 and also could manufacture according the angles given by the clients. |
|
Connection |
Butt-welding |
|
Applicable standard |
ASME,ASTM,MSS,JIS,DIN,EN |
|
Quality:ISO 9001 |
ISO2000-Quality-Systerm has been passed |
|
End Bevel: |
According to the bevel of welding pipe fittings construction |
|
Surface treatment: |
Shot blasted, rust-proof black oil. |
|
Packing: |
wodden case,wooden pallet plastic bag or as per customers' requirements |
Common Carbon Steel Elbow Sizes
|
Nominal Size |
Outside Diameter |
|
1/2" |
21.3 mm |
|
1" |
33.4 mm |
|
2" |
60.3 mm |
|
4" |
114.3 mm |
|
6" |
168.3 mm |
|
8" |
219.1 mm |
|
12" |
323.9 mm |
|
24" |
610 mm |
Carbon Steel 45 Degree Elbow Types
|
Type |
Description |
|
Long Radius (LR) 45° Elbow |
Radius = 1.5 × pipe diameter |
|
Short Radius (SR) 45° Elbow |
Radius = 1 × pipe diameter |
|
Seamless Elbow |
Hot formed from seamless pipe |
|
Welded Elbow |
Fabricated from plate/pipe |
|
Induction Bend |
Large radius bending |
Hot Tags: carbon steel 45 degree elbow, China carbon steel 45 degree elbow manufacturers, suppliers, factory
