3PE Coated Pipe
Outer Diameter: 60.3mm~1422.4mm
Wall Thickness: 3mm~50mm
3LPE coating thickness: 1.8mm~4.5mm
Length: 6m-12m or as per customer’s requirement
Product Name: 3PE Coating Steel Pipe
Outer Diameter: 60.3mm~1422.4mm
Wall Thickness: 3mm~50mm
3LPE coating thickness: 1.8mm~4.5mm
Length: 6m-12m or as per customer's requirement
Pipe Material: Q195~Q235, 10#~45#, Gr.A~Gr.C, X42~X70, S235~S355 etc.
3LPE Coating Standard: DIN30670, CAN/CSA-Z245.21, NF A49-710, GB/T23257, SY/T0413 etc.
3PE coating steel pipe, also known as three-layer polyethylene coating, is a type of anti-corrosion coating used in the manufacture of steel pipe. It is a three-layer coating consisting of a fusion-bonded epoxy (FBE) primer, an adhesive layer, and a polyethylene topcoat.
The FBE primer provides excellent adhesion to the steel surface, while the adhesive layer ensures optimal bonding between the primer and the topcoat. The polyethylene topcoat provides a barrier against chemical and corrosive elements, making the steel pipe highly durable and long-lasting.
3LPE Steel Pipe Anti-corrosion Structure
It is an Anti-corrosion form of outer surface of steel pipe
3PE anti-corrosion coating generally consists of 3 layers:
The 1st layer of epoxy powder (FBE>100μm)
The 2nd layer of adhesive (AD) 170 ~ 250μm
The 3rd layer of polyethylene (PE) 2.5 ~ 3.7mm
Applications of 3PE Coating Steel Pipe
Our 3PE coating steel pipe finds extensive use in a wide range of applications. Some of the applications include:
Oil and gas industry: Our product is ideal for use in the oil and gas industry, where it is used to transport oil and gas over long distances.
Water supply systems: Water transmission systems also require our product for its high durability, making it ideal for long-term use.
Chemical and petrochemical industry: The resistance to chemical corrosion makes our product suitable for chemical and petrochemical industry applications.
Mining industry: The abrasive resistance of our product makes it ideal for use in the mining industry as mining companies need a reliable material for transporting minerals.
